Wafer Butterfly Valve With Worm Gear
  • Wafer Butterfly Valve With Worm GearWafer Butterfly Valve With Worm Gear
  • Wafer Butterfly Valve With Worm GearWafer Butterfly Valve With Worm Gear
  • Wafer Butterfly Valve With Worm GearWafer Butterfly Valve With Worm Gear
  • Wafer Butterfly Valve With Worm GearWafer Butterfly Valve With Worm Gear
  • Wafer Butterfly Valve With Worm GearWafer Butterfly Valve With Worm Gear
  • Wafer Butterfly Valve With Worm GearWafer Butterfly Valve With Worm Gear

Wafer Butterfly Valve With Worm Gear

FYL is factory located in Tianjin China. Factory specialized in producing different type of valves. Wafer butterfly valve with Worm Gear is one of major products. Our products has good quality and price advantage, also company available to make OEM products. Welcome inquiries from all over the world.

Send Inquiry

Product Description

Product Overview:

The wafer butterfly valve with worm gear is designed for efficient, reliable control of liquids, gases, or slurries in piping systems. This valve uses a circular disc (the "butterfly") as the closure mechanism, which rotates around an axis perpendicular to the flow. When the disc is turned, it either opens or closes the valve, thus regulating the flow of the medium.

Key Features:

Wafer-style Body: The wafer design is compact and lightweight, making it easy to install between flanges in a pipeline without requiring additional flange drilling. It is held in place using bolts that thread through the flanges and the valve body.

Worm Gear Operation: The valve is equipped with a worm gear actuator, which allows for manual operation. The worm gear mechanism reduces the effort required to operate the valve, providing precise control with minimal hand force.

Disc and Seat: The valve's disc is usually made from durable materials like stainless steel, and the seat is lined with an elastomer such as EPDM, PTFE, or rubber, ensuring a tight seal to prevent leaks.

Quarter-turn Valve: This type of valve is operated with a simple 90-degree turn of the handle or gear, making it a quick and efficient option for on/off or throttling applications.

Flow Control: The butterfly valve provides excellent flow control with low-pressure drops, making it suitable for both throttling and isolation applications.

Corrosion Resistance: With material options like stainless steel, ductile iron, or other high-grade alloys, these valves offer high resistance to corrosion, suitable for use in various chemical, water treatment, and industrial applications.

Size Range: Available in a variety of sizes to accommodate different pipe diameters, typically ranging from 2 inches (50mm) to 48 inches (1200mm) or more.

Applications:

· Water supply and treatment systems

· HVAC systems

· Oil and gas pipelines

· Chemical and pharmaceutical industries

· Food and beverage processing

· Power generation plants

Advantages:

· Space-saving design

· Low maintenance

· Easy to install and operate

· Long service life

Parameter

Shell test (MPa)

1.5MPa、2.4MPa、3.0MPa

Seal test (MPa)

1.1MPa、1.76MPa、2.2MPa

Operation

Hand wheel,pneumatic, electric,worm gear

applicable medium

Water,sewage,sea water,air, steam

Worm gear

DN

L±2

D1

H2

H1

Z-d

n-M

150

56

240

185

140

4-Φ22

8-M20

200

60

295

215

175

4-Φ22

8-M20

250

68

350

245

206

4-Φ22

12-M20

300

78

400

285

242

4-Φ22

16-M20

350

78

460

305

265

4-Φ22

16-M20

400

102

515

357

308

4-Φ22

16-M20

450

114

565

385

330

4-Φ26

20-M24

500

127

620

450

350

4-Φ26

20-M24

600

154

725

510

410

4-Φ30

20-M27

700

168

840

550

480

4-Φ30

20-M27

Hot Tags: Wafer Butterfly Valve With Worm Gear, China, Manufacturers, Suppliers, Factory, Price, Made in China
